S&P TCBBX2 Double / Twin Turbo Cased Axial Fan – Soler & Palau, Single Phase, IP65 (450–630mm)
S&P TCBBx2 High-Efficiency Contra-Rotating Cased Axial Fans
The TCBBx2 contra-rotating cylindrical axial fan by Soler & Palau features two complementary aluminium impellers rotating in opposite directions to significantly increase static pressure and overall efficiency. It remains one of the best-performing high-pressure fans in its class.
Technical Specifications
- Fan diameter: 450mm, 500mm, 560mm, 630mm
- Design: Two contra-rotating die-cast aluminium impellers, dynamically balanced to ISO 1940 for vibration-free operation
- Casing: Galvanised steel with anti-corrosion cataforesis primer and black polyester paint finish, stainless steel fixings
- Protection rating: IP65
- Insulation class: Class F, with thermal overload protection
- Continuous airstream temperature: -40°C to +70°C
- Electrical supply: Single phase, 220-240V, 50Hz
- Indicative performance: the 500mm size delivers up to approximately 6,380 m³/h at around 500 Pa static pressure (1394 rpm)
Because absorbed power, noise level, and weight vary between motor sub-variants (H/L configurations), contact us with your required diameter and we'll confirm the exact performance curve for your specific model.
Available Sizes & S&P Model Codes
Every size of the S&P TCBBX2 range is listed below with its exact Soler & Palau model code, so you can match it to your specification or the fan you are replacing.
| Size | S&P model code | Order |
|---|---|---|
| 450mm | S&P TCBBX2/4-450 | Select 450mm |
| 500mm | S&P TCBBX2/4-500/L | Select 500mm |
| 500mm long case | S&P TCBBX2/4-500 | Select 500mm long case |
| 560mm | S&P TCBBX2/4-560 | Select 560mm |
| 630mm | S&P TCBBX2/4-630 | Select 630mm |
Typical Applications
- High-pressure commercial kitchen extract where standard axial fans would stall
- Long or complex duct runs with significant system resistance
- Greasy extraction applications requiring higher static pressure
